How to Read Kenmore Model Numbers, and What Changes Once You Have

How to read Kenmore model numbers: three digits, then everything else

Every other page on this site depends on you being able to do this, so it is worth two minutes.

The model number on the rating plate looks like 110.44832400. Read it as two parts. The three digits in front of the period are a manufacturer code. Everything after the period identifies the individual machine inside that manufacturer's own range — and it is that second half a parts supplier searches on, usually with the period taken out.

The badge itself is not a manufacturer. It is a house brand: a name that was put on appliances built under contract by other companies, and the contracts moved. That is why two machines bought three years apart under the same name can share nothing but the sticker on the front.

What each group of digits names

Two of those are worth a sentence each. 911 is a range prefix, not a laundry one — it appears on lists of washer codes fairly often and every genuine 911 we have seen is a range. And 630 is missing from most of the decode tables in circulation, which is exactly why a 630 gets looked up against the wrong company's material more than anything else on this list.

What actually changes once you know

This is the part that makes the number worth finding.

The parts catalog changes. The component in your machine has a manufacturer's part number, and that manufacturer is the one the three digits name. A number that returns nothing has usually been superseded rather than discontinued, and finding the superseding number means searching the right company's catalog.

The documentation changes. A tech sheet, a wiring diagram and a service manual exist for your machine, under the builder's own model designation. They do not exist under the badge.

The code table changes. This is the one that costs people money. A display reading two letters on an LG-built machine and a display reading F and a number on a Whirlpool-built one are two different languages, and they overlap enough to be convincing. Read LF against the wrong table and you get a confident answer about the wrong component.

And sometimes there is no table at all. A Roper-built range publishes nothing a homeowner can look up, and neither does a hood. Knowing that in advance saves an hour of searching for a list that does not exist.

What it does not change

It does not change who repairs it. Whatever the door says, the appliance on the floor was engineered by Whirlpool or LG or Frigidaire, and that is how it gets worked on — with the builder's own parts and the builder's own documentation.

It also does not make an older machine worse. Some of the best-built appliances in South Florida kitchens are wearing this badge, because the contract that year went to a company at the top of its game. The number is not a verdict. It is an address.

The one thing to write down

Photograph the plate. Not the number typed into a phone — the plate itself, with the serial and the electrical rating in the frame. Half the calls that stall stall because somebody read a 5 as an S, and a photograph settles it in a second.
