- “A bake element usually shows visible damage”
- “A sensor problem shows nothing at all”
- “A consistent offset is the sensor's signature”
Symptom
Kenmore oven not heating
Two answers cover most of these and they are cheap to tell apart. A failed bake element usually shows itself, and a temperature sensor that has drifted does not show anything at all — it simply reports the wrong number and the oven confidently holds a temperature it is not at.
- From $95 diagnostic, credited to the repair
- 59 cities and neighborhoods covered
- OEM parts available on order
- In writing the price, before anything is opened
Five ordinary causes
What this usually turns out to be
Cheapest and commonest first, which is also the order we check them in. They sit hundreds of dollars apart, and only the unit settles which one is yours.
-
The bake element has failed
Often visible, always testable, and an inexpensive part on a freestanding range.
Oven element replacement from $165 -
The oven temperature sensor
It looks like nothing and reports the wrong number. An oven out by a consistent amount is this.
Oven sensor and calibration service from $145 -
Demonstration mode
The panel works and the oven does not heat, on purpose. Worth ruling out on a floor-model purchase.
Diagnostic visit from $95 -
The igniter, on a gas oven
A weak igniter glows and never draws enough current to open the gas valve. That is the commonest gas oven failure.
Surface igniter replacement from $165 -
The relay board or control
Where the element and the sensor both test good and nothing is switching them on.
Appliance control board repair from $265
In five minutes
Before you call anybody
None of it needs tools, and all of it makes the visit shorter.
-
01
Electric or gas
It decides the whole list.
-
02
Look at both elements
Cold, with the oven off. Blisters and breaks are visible.
-
03
Measure with an oven thermometer
Set 350 and see what it holds. A consistent offset is very different from no heat.
-
04
On gas, watch the igniter
Bright orange within a minute, and then flame. A dull glow that never produces a flame is the diagnosis.
How it shows up
What people describe when they call
A shortcut
Narrow it down before anybody arrives
A description of the behaviour leaves a few possible causes. A code names the subsystem before anybody opens anything, which is why it is worth photographing before it clears.
If there is no code at all
36275321002
36275585891
36275620302
36291112001
66575004101
79036733700
79071452601
79073232314
79078642601
79092603012
79095059310
91145565690
On a range, the data plate is behind the kick panel or on the frame under the oven door. On a wall oven, the data plate is on the side of the opening behind the door. All models
In more detail
About Kenmore oven not heating
Look at the elements before anything else
On an electric oven, look at both elements while they are cold. A bake element that has failed very often shows a blister, a break or a bright annealed spot. And an oven that browns the top of everything and never cooks it through is running on the broil element alone, which is a diagnosis you can make from the kitchen.
What it usually means, by the company that built it
Kenmore manufactures nothing, so the same behavior points at different things depending on who made the appliance. The three digits before the period on the rating plate are what tells them apart.
- 790 Frigidaire — F30 is Frigidaire's open probe and F31 is a shorted one — the two ways the oven temperature sensor circuit fails. F10 is their thermal runaway, which is the opposite problem and should not be left running.
- 362 GE — GE-built 362 ranges are a smaller part of this catalog and their tables are not published here yet.
- 911 Roper — Roper publishes no codes at all. A 911 range is diagnosed by symptom and by measurement, which is a real method and the only honest one here.
Why an oven can be wrong and confident
An oven holds temperature by comparing what its sensor reports against what you asked for. If the sensor reads low, the oven keeps heating past the setting; if it reads high, the oven stops short. In both cases the display shows what you asked for, because the display is reporting the request rather than the reality. That is why the first tool on this symptom is an independent thermometer.
The weak igniter
On a gas oven the igniter does two jobs: it glows hot enough to light the gas, and the current it draws is what opens the gas valve. As it ages it still glows — visibly, reassuringly — while drawing too little current to open the valve. So the classic complaint is an oven that glows and never lights, and the part that looks like it is working is the one that has failed.
This article is based on:
- Official manufacturer documentation
- Internal repair procedures
- Technician repair history
- Company quality standards
Before you book
Questions about Kenmore oven not heating
It heats but everything burns on top.
That is the bake element out and the broil element carrying the oven on its own. It is a definite diagnosis from the kitchen.
My oven is 25 degrees out. Can that be adjusted?
Usually yes — most of these have a calibration offset in the control. Where the error drifts rather than staying constant, calibrating over it only hides a failing sensor.
It is a Kenmore, so who actually made it?
The first three digits tell you. 790 is a Frigidaire, 362 is a GE, 911 is a Roper. It changes the parts and it changes whether there is a code table at all.
